The inclined guide pin 2 and side insert 1 are in the stationary mold as shown in Fig 7.16. The inclined guide pin 2 is fixed in the stationary clamping plate, and the side insert 1 can moves on the stationary ejector plate 4.
Operation: when the mold opens, the stationary ejector plate 4 and stationary frame plate 11 move together with mobile mold parts, because the stationary ejector systems are interconnected by hook 9. The side insert I is pulled out of the workpiece by guide pin 2 fixed in the stationary clamping plate. Upon completion of the movement of side insert, the dome the side hook 10 pushes the nose of hook 9 revolving around shaft 7 and out of mobile mold, the main parting line opens. The workpiece is pushed out of the forming core 3 by ejector plate 5 connected to ejector pin 14
